Feature
- Stainless steel structure, durable, with minimal noise and smooth operation.
- High speed homogenization, without dust, bubbles, or sagging.
- The planking height is flat, without deformation or leakage, saving silicone.
- Avoiding the disadvantages of easy crushing of glass, large volume, and uneven laying of boards by roller laying machines.
Instrument composition
Main body, high-speed homogenizer, adjustable thickness slurry tank, shelf washing rack.
Main Parameter
- Planking thickness: continuously adjustable between 0~3mm, covering a full range of products from high-efficiency boards to preparation boards.
- Plank width: 200 mm and 100 mm thin layer chromatographic plates, respectively.
- Board laying speed: 10 seconds per process, capable of continuous operation 24 hours a day.
- Single board production quantity: 200 different specifications and quantities can be laid each time × 200 mm -4 sheets, 200 × 100 mm -8 sheets, 100 × 100mm -16 sheets.
- Power supply: 220V 50HZ 10W.
