Features
- Integrated with incubator and shaker to save space and cost.
- ABS shell, polished stainless steel chamber.
- Large LCD screen to display temperature and shaking speed.
- With operation datamemory function to eliminate faulty operation.
- Non-volatile memory saves settings during a power outage and automatically restarts the unit as originally programmed after power is restored.
- Auto-stop operationwhen door is opened. Strong air spring rod with easy opening and closing.
- Brushless DC motor, more stable and
- Equipped with leakage protection.
Specifications
|
Model |
LYZ-103B |
LYZ-100B |
LYZ-200B |
|
Shaking Speed |
20-300 rpm |
||
|
Speed accuracy |
±1 rpm |
||
|
Swing amplitude |
Φ26 mm |
||
|
Standard configuration |
100ml×9 |
50ml×4, 100ml×4, 250ml×3, 500ml×3 |
50ml×5, 100ml×5, 250ml×4, 500ml×3 |
|
Maximum capacity |
50ml×12,100ml×9 |
50ml×20 or 100ml×16 or 250ml×12 or 500ml×9 |
100ml×20 or 250ml×16 or 500ml×12 or 1000ml×5 or 2000ml×4 |
|
Tray Size |
295×253 mm |
400×370 mm |
450×410 mm |
|
Timing Range |
1-9999min |
||
|
Temperature Range |
RT+5～60 ℃ |
RT+5～60 ℃ |
4～60 ℃ (Cooling) |
|
Temperature Accuracy |
±0.1 ℃ |
||
|
Temperature uniformity |
±1 ℃ |
||
|
Display |
LCD |
||
|
Tray Included |
1 |
||
|
Exterior Size (W×D×H) |
440×410×390 mm |
600×580×510 mm |
780×682×560 mm |
|
Package Size (W×D×H) |
580×530×540 mm |
740×700×660 mm |
920×800×610 mm |
|
Net/Gross weight |
31/41 kg |
72/88 kg |
100/125 kg |
|
Volume (W×D×H) |
320×295×190 mm |
440×405×270 mm |
480×450×320 mm |
|
Power Rating |
220W |
320W |
580W |
|
Power Supply |
AC 220～240V, 50～60Hz |
||
