Features:
■ We adopt the microcomputer processor as the control center of DYY-7C; ON/OFF switch. DYY-7C has the following strong points:small, light, high output-power, stable functions.
■ The LCD can show you the following info.at the same time: voltage, electric current, pre-assigned time, etc..
■ It has the warning function of timing.
■ It has the function of storing the operation parameters of last time.
■ It can work in the constant state of voltage, or in the constant state of electric current, and it can be converted automatically according to the pre-assigned parameters for different needs.
■ It has the protection function when it is under the circumstances of the unloaded, overload, suddenload change and when it is beyond the limitation.
■ Parameters can be adjusted finely during the running.
■ Output terminals: 4 pairs in parallel.
Application:
DYY-7C is very suitable for trans-blotting electrophoresis.
Specifications
■ Power requirement:A.C. 220V±10% (50Hz ±2% ).
■ Input power: about 500 VA.
■ Output voltage: (2-300)V (Increase or decrease:1V/step).
■ Output current: (5-2000) mA (Increase or decrease:2mA/step).
■ Rated output power: 300 W.
■ Stability: constant voltage ≤1%; constant current ≤2%.
■ Adjustment rate:constant voltage ≤2%; constant current ≤3%.
■ Size(W x D x H): 315 x 290 x 128 (mm).
■ Weight: about 5.0 kgs.
